Cisco Switch Configuration


When executing an inter-network installation, many mechanisms and components are usually involved. Cisco is superior because it is the only inter-networking company with a well made end to end inter-networking solution. Cisco switches makes the LAN more competent by creating multiple collision domains. Each switch port is a split collision domain. With only one device connected per port, collisions are not probable and communications are more efficient. Cisco switches are very capable because they perform packet filtering and forwarding in hardware as opposed to software. Cisco switches increase the speed of work.

Cisco Switch Configuration

A new Cisco switch is not configured by default. Users have to configure the switch with the configuration dialogue in setup mode. After the basic switch configuration is performed in setup mode, the user can verify, modify, and delete the switch’s configuration settings in different configuration modes with the Cisco IOS command line interface. Cisco IOS’s two primary modes are user exec mode and privileged exec mode along with configuration modes such as global configuration mode, interface configuration mode, and line configuration mode with distinctive prompts. Each mode has specific commands to perform specific tasks. The user exec mode is the limited examination mode, while the privileged exec mode is the detailed examination and the prerequisite for all other configuration modes. Global configuration mode is the mode for the switch’s  global settings, while the interface configuration mode and line configuration mode configure the specific interface or line. Cisco IOS commands in the different Cisco switch series vary. Nowadays, the most popular Cisco switch series are the Cisco Catalyst 2950 series switch, Cisco 2960 series switch, and Cisco 3548 series switch.cisco switch configuration Cisco Switch Configuration

Cisco Switch Configuration Commands

It is important to know the basic cisco switch configuration with the cisco switch configuration commands and basic operational cisco switch commands so that any internetwork performs.
Here are some basic configuration and operation commands of cisco switches:
  • interface vlan 1: This is a global command that configures the interface for VLAN.
  • ip default-gateway [address]: This is a global command and set default gateway.
  • ip address [address][subnet mask]: This command configures the interface and sets the ip address.
  • interface fast Ethernet 0/x: This command puts users into user configuration mode.
  • speed {10/100/1000/auto/nonegotiate}: This command sets the interface’s speed.
  • duplex {auto/full/half}: This command sets duplex mode for the interface.
  • switchport port-security mac-address: This command statically adds a MAC address as the allowed address on the port.
  • switchport port-security mac-address sticky: This command tells switch to learn MAC addresses on the interface and add as secure MACs.
  • switchport port-security violation {protect/restrict/shutdown}: This command tells the switch what to do if an appropriate MAC tries to access through secure switch port.
  • switchport port-security maximum [value]: This command allowed max of secure MAC on the interface.
  • hostname [name]: This command assigns a host name to the switch.
  • line vty 0 15: This command enters vty configuration mode.
  • line con 0: This command enters console configuration mode.
  • login: This command tells the switch to ask for a password.
  • password[password]: This command sets the password.
  • enable password [password]: This command sets the password to enter privileged mode.
  • enable secret [password]: This command sets encrypted password.
  • configure terminal: This command enters configuration mode.
  • show interfaces fastethernet 0/x: This command displays interface status.
  • show interfaces: This command displays information about a specific interface.
  • show interfaces vlan 1: This command displays the ip address configuration.
  • show [running/startup]-config: This command displays RAM/NVRAM settings.
  • show-mac-address-table: This command displays the MAC address table.
  • show port-security: [interface] [address]: This command shows security options on the interface.
  • show version: This command displays the switch’s hardware and software status.
  • show flash: This command displays the files and directories in the flash.
  • show history: This command displays the last ten commands.
  • erase startup-config: This command erases startup configuration.

Cisco 2960 Switch

The Cisco Catalyst 2960 switch is one of the popular series that the Cisco System introduced with a management console. There are two different models in Cisco Catalyst 2960 series switch with all uplink ports. One model has 12 fast Ethernet interfaces and the other has 24 fast Ethernet interfaces. The Cisco Catalyst 2960 series switch is mostly used in the industrial or ISP sector for its better performance and scalability features.

Assigning IP to Cisco 2950 Switch

Users can assign an ip address to the Cisco 2950 switch with this global configuration mode command.
Switch2950 (config) # interface vlan 1
Switch2950 (config-if) # ip address 192.168.0.1 255.255.255.0

How to Configure a Cisco 3548 Switch

Configuring a Cisco 3548 switch is very simple. Connect the Cisco 3548 switch’s console port with the computer’s com port by using the UTP roll over cable. After physical connection, make a HyperTerminal session and give it any name. The com port setting should be Restore Default in the com port’s properties. Configure the basic configuration settings in setup mode with the configuration dialogue’s help. The basic configuration includes the configuring of hostname, configuring the enable secret password, enable password and the line vty password, and the configuration of each fast Ethernet interface along with the VLAN interface configuration. The vlan interface’s ip configuration is also included in the basic configuration.

How to configure OSI Bridging on Cisco Switch

In order to configure the OSI bridging on a Cisco switch, use the command “bridging” in the Cisco switch’s global configuration mode.
